81
Alarms
Throughout a program cycle there are several abnormal events that could occur. The
washer is programmed to monitor these occurrences and provide an alarm to alert the
user. Information is displayed to identify the alarm situation, which may be Fatal or
Non-Fatal to the running program. See Table 7-1 for a list of all Alarm Codes and their
description. Fatal alarms during a cycle will drain the washer, end the program and
display a red X on the segment in which the error occurred. Non-Fatal alarms will allow
the program to proceed. The display will show a yellow check mark at any complete
segment in which a non-fatal alarm occurred. Touching the red X or yellow check will
display alarm details and the time of occurrence.
Completing the Wash Cycle
The wash cycle can be terminated at any time by pressing the Cancel Icon and
confirming the cancelation. The washer will drain and end the cycle. The progress bar
will display a red X at the segment in which the program was cancelled.
If the cycle is completed with no interruptions or alarms, the progress bar will display
blue checks at each segment, and a Program Complete pop-up will display until
acknowledged.
If Auto-Unlock was enabled in the program, once the internal temperature is below 50
o
C
the door latch will open to allow the washer to vent and assist drying.
ALARM
CODE
ALARM DESCRIPTION CONDITION RESPONSE
A1 LOW AUTO RINSE AID 1 Low Rinse Aid in Auto Dispense * NON-FATAL
D1 LOW DETERGENT 1 Low Detergent in Auto Dispense * NON-FATAL
DF DRAIN FAIL Pressure Sensor did not reach 0 during drain FATAL
DL DOOR LATCH FAIL Door unlatched during cycle FATAL
DO DOOR OPEN Door not fully closed FATAL
FF FILL FAIL Low Water after allotted fill time expires FATAL
FI FIRMWARE
Firmware Unresponsive NON-FATAL
HW HIGH WATER Fill Level too high during segment FATAL
LT LOW TEMP Temperature Set Point not achieved FATAL
NW NO WATER No or Low Water during segment FATAL
OV OVER FLOW Water detected in base FATAL
PC PROGRAM CANCELED User initiated Program Cancel FATAL
PF POWER FAIL Power Loss occurred NON-FATAL
PP PROGRAM PAUSED User initiated Program Pause NON-FATAL
RA RINSE AID LOW D-CUP Low Rinse Aid in Detergent Dispense NON-FATAL
SS STEP SKIPPED User initiated Segment Skip NON-FATAL
TS TEMP SENSOR Temp Sensor error or disconnected FATAL
* Only on models with optional Auto Dispense or Rinse-Aid Dispense accessory installed.
Table 7-1
