Page 15
BLOWER DATA - DIRECT DRIVE - KGB024
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (larger gas heat section, economizer, wet coil, etc.) See page 41.
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.) See page 41.
External Static
Pressure (in. w.g.)
Air Volume (cfm) at Various Blower Speeds
208 VOLTS 230 VOLTS
High Medium Low High Medium Low
2 Ton Standard Efciency (Downow) KGB024S
0.0 1275 979 878 1453 1140 926
0.1 1262 960 834 1440 1124 912
0.2 1243 938 790 1420 1096 884
0.3 1218 909 746 1396 1065 853
0.4 1186 866 710 1352 1033 822
0.5 1137 838 657 1316 986 774
0.6 1104 795 604 1263 954 727
0.7 1055 752 534 1210 906 680
0.8 990 694 463 1158 859 632
0.9 925 637 392 1070 764 538
1.0 794 523 290 928 669 477
2 Ton Standard Efciency (Horizontal) KGB024S
0.0 1204 937 818 1370 1098 879
0.1 1186 913 788 1352 1066 864
0.2 1164 882 748 1327 1034 839
0.3 1137 860 710 1300 1001 809
0.4 1104 818 670 1263 968 768
0.5 1070 775 612 1227 925 728
0.6 1031 733 554 1190 881 688
0.7 991 690 500 1136 816 628
0.8 937 626 432 1081 751 557
0.9 804 566 362 1009 665 492
1.0 678 497 287 900 565 416
