Page 29
BLOWER DATA - DIRECT DRIVE - KCB030
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (economizer, wet coil, etc.) See page 41.
2 - Any eld installed accessories air resistance (electric heat, duct resistance, diffuser, etc.) See page 41.
External Static
Pressure (in. w.g.)
Air Volume (cfm) at Various Blower Speeds
208 VOLTS 230 VOLTS
High Medium Low High Medium Low
2.5 Ton Standard Efciency (Downow) KCB030S
0.0 1199 928 838 1379 1085 877
0.1 1229 926 813 1409 1086 872
0.2 1206 928 782 1367 1094 850
0.3 1183 881 742 1350 1047 820
0.4 1159 843 686 1321 1009 783
0.5 1136 812 643 1282 981 762
0.6 1103 766 569 1242 921 705
0.7 1046 728 496 1195 888 625
0.8 953 648 432 1134 792 583
0.9 909 584 335 1037 738 492
1.0 783 465 247 926 592 411
2.5 Ton Standard Efciency (Horizontal) KCB030S
0.0 1152 909 801 1325 1063 838
0.1 1152 893 770 1321 1048 826
0.2 1136 866 734 1288 1021 798
0.3 1104 826 697 1260 982 771
0.4 1072 787 643 1222 942 734
0.5 1041 747 589 1175 903 698
0.6 1009 707 534 1137 850 662
0.7 946 654 467 1081 797 588
0.8 861 588 396 1024 718 535
0.9 798 508 319 911 642 468
1.0 715 443 237 846 564 394
