BLOWER DATA - DIRECT DRIVE - KCB060
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (economizer, wet coil, etc.) See page 41.
2 - Any eld installed accessories air resistance (electric heat, duct resistance, diffuser, etc.) See page 41.
External Static
Pressure (in. w.g.)
Air Volume (cfm) at Various Blower Speeds
208 VOLTS 230 VOLTS 460/575 VOLTS
High Low High Low High Low
5 Ton Standard Efciency (Downow) KCB060S
0.0
1883
1570 2074 1785 2074 1785
0.1 1871 1550 2050 1760 2050 1760
0.2 1855 1538 2018 1735 2018 1735
0.3 1828 1523 1986 1704 1986 1704
0.4 1786 1499 1937 1679 1937 1679
0.5 1759 1476 1905 1642 1905 1642
0.6 1718 1452 1856 1605 1856 1605
0.7 1676 1421 1791 1567 1791 1567
0.8 1622 1358 1726 1505 1726 1505
0.9 1539 1277 1628 1406 1628 1406
1.0 1399 - - - 1502 1300 1502
1300
5 Ton Standard Efciency (Horizontal) KCB060S
0.0
1852
1534 2046 1713 2046 1713
0.1 1844 1532 2024 1711 2024 1711
0.2 1831 1526 1998 1706 1998 1706
0.3 1800 1504 1954 1681 1954 1681
0.4 1769 1477 1918 1654 1918 1654
0.5 1722 1450 1865 1612 1865 1612
0.6 1674 1423 1812 1570 1812 1570
0.7 1627 1369 1742 1515 1742 1515
0.8 1565 1315 1672 1459 1672 1459
0.9 1470 1241 1530 1376 1530 1376
1.0 1323 - - - 1426 1242 1426 1242
