TABLE 15
KGB/KCB030 Normal Operating Pressures
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
118 227 118 271 119 316 121 365 123 422 125 486
126 230 128 266 129 309 130 367 131 425 134 493
144 235 147 272 150 312 151 358 151 417 153 488
163 245 167 279 171 319 173 363 176 412 177 465
TABLE 16
KGB/KCB036 Normal Operating Pressures
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
114 237 115 271 117 317 119 369 122 426 124 503
122 238 123 269 126 318 128 366 130 422 133 492
141 246 144 277 146 321 148 369 149 425 152 489
162 254 165 287 168 330 171 377 173 428 176 497
TABLE 17
KGB/KCB048 Normal Operating Pressures
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
114 251 116 285 117 334 119 382 121 436 123 500
122 255 125 292 127 336 128 385 130 439 132 502
139 265 142 300 145 343 148 391 150 440 153 499
155 277 159 313 164 356 167 403 171 454 174 510
TABLE 18
KGB/KCB 060 Normal Operating Pressures
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
110 239 112 284 114 329 116 379 118 437 120 532
118 242 121 286 123 329 125 379 127 433 130 495
136 252 139 294 141 337 144 382 147 435 152 488
153 265 158 304 161 345 163 390 165 442 173 494
TABLE 19
KGA/KCA 072 Normal Operating Pressures
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
106 250 111 288 115 329 118 375 121 428 124 482
110 256 116 295 122 338 126 383 129 434 132 490
124 254 130 309 135 351 141 398 146 449 149 508
138 289 145 329 151 373 157 422 163 473 169 527
