Page 31
BLOWER DATA - DIRECT DRIVE - KCA060
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (economizer, wet coil, etc.) See”BLOWER DATA” on page 41.
2 - Any eld installed accessories air resistance (electric heat, duct resistance, diffuser, etc.) See”BLOWER DATA” on page 41.
External Static
Pressure (in. w.g.)
Air Volume (cfm) at Various Blower Speeds
208 VOLTS 230 VOLTS 460/575 VOLTS
High Low High Low High Low
5 Ton Standard Efciency (Downow) KCA060S
0.0 2121 1644 2324 1952 2160 1750
0.1 2162 1660 2315 1991 2128 1733
0.2 2100 1704 2285 1946 2092 1712
0.3 2078 1667 2230 1928 2054 1687
0.4 2056 1646 2185 1909 2005 1652
0.5 2014 1626 2154 1873 1972 1629
0.6 1953 1592 2049 1821 1907 1583
0.7 1913 1594 1966 1787 1858 1549
0.8 1830 1519 1936 1715 1810 1515
0.9 1774 1509 1763 1650 1744 1469
1.0 1601 1319 1649 1508 1679
1400
5 Ton Standard Efciency (Horizontal) KCA060S
0.0 2038 1611 2222 1875 2225 1885
0.1 2026 1601 2194 1866 2236 1895
0.2 1978 1590 2145 1833 2186 1853
0.3 1940 1563 2096 1800 2137 1818
0.4 1902 1537 2047 1766 2106 1799
0.5 1845 1497 1973 1716 2031 1763
0.6 1787 1470 1924 1666 2002 1711
0.7 1730 1431 1850 1616 1970 1677
0.8 1653 1378 1776 1549 1853 1607
0.9 1558 1312 1677 1449 1800 1586
1.0 1462 1257 1579 1377 1750 1418
