KG/KC 024, 030, 036, 048, 060, 072, 074, 090
TABLE 20
KGB/KCB 074S & H Normal Operating Pressures
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
112 257 113 298 114 348 116 403 118 476 121 602
120 261 122 301 123 347 124 403 127 466 129 556
136 271 140 310 143 354 145 401 145 460 147 525
154 290 157 327 161 370 165 416 168 468 171 526
TABLE 21
KGA/KCA 090 Normal Operating Pressures
Outdoor Coil Entering Air Temperature
65 °F 75 °F 85 °F 95 °F 105 °F 115 °F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
107 268 109 309 113 357 116 403 118 449 123 503
115 275 118 314 120 358 123 406 126 458 130 513
131 286 134 327 137 376 140 421 144 477 147 537
147 307 151 344 154 390 158 441 162 495 167 558
60
70
80
90
100
110
120
110 120 130 140 150 160 170
Liquid Temperature (° F)
Suction Pressure (psig)
Outdoor Temperature (°F)
KGB/KCB 024 Charging Curves
115°
105°
95°
85°
75°
65°
180
