58 Information SET-02
16 Troubleshooting Guide
Malfunction Possible cause Correction
SET-02 is not
operational
(LED on LV200 does
not light up)
Power supply is interrupted,
transformer is not plugged into
an outlet or "U", "V" wires are
not connected to the
transformer.
Ensure that the
transformer is on, has not
overloaded or shut off,
check wiring from
transformer to LV200
LED flashes green,
locomotives do not
run, points and
The connection between LV200
and command station LH200 is
broken, or there is a short circuit
(terminals C and D)
Check and correct these
connections.
signals can not be
switched.
The emergency Stop key has
been pressed
Press the emergency stop
key again
You are in programming using a
programming track
When finished program-
ming turn the power to the
LH200 on and off
LED shines
constantly red,
There has been a short-circuit on
the track system.
Deal with the short-circuit.
locomotives do not
run, points and
signals can not be
switched.
There is overloading. Divide the system into
several coverage areas
and supply them with
additional s/ transformers
LV200 is operational
(LED shines green),
locomotives do not
run, and turnouts
and signals can not
be switched.
The connection of the power
station and the track and / or the
switch decoder is interrupted
(terminals J and K not
connected).
Check and correct the
connections.
Throttle notch setting
can not be altered
Speed of the locomotive is not 0 Before setting the throttle
position mode turn the
rotary control-knob as far
to the left as possible
Locomotive does not
run when throttle
notch mode 128 has
been selected
Locomotive decoder does not
support 128 speed step mode
Set running-notch mode 14
or 28
