Free connection of analog signals
Free configuration of analog input signals
10
Function library
10.12
10.12.1
L
10.12-1
EDS82EV903-1.0-11/2002
10.12 Free connection of analog signals
10.12.1 Free configuration of analog input signals
l Internal analog signals can be freely assigned to external analog signal
sources:
– Analog inputs (X3/8, X3/1U, X3/2U, X3/1I, X3/2I)
– Frequency input
– Function “Motor potentiometer”
– Analog process data input words
l A signal source can be assigned to several targets.
)
))
) Note!
Use C0005 to configure some of the signal sources for analog
inputs. The corresponding subcodes of C0412 will be adapted
automatically.
Description
