Free connection of analog signals
Free configuration analog process data output words
10
Function library
10.12
10.12.3
L
10.12-10
EDS82EV903-1.0-11/2002
10.12.3 Free configuration analog process data output words
l The analog process data output words can be freely assigned to internal
analog process signals or monitoring signals. The controller outputs a value
proportional to the internal signal on the bus. The normalisation is indicated
under C0421.
l A signal source can be assigned to several targets.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0421*
v
Free configuration
analog process
data output words
Output of analog signals on bus
^
10.12-10
1 AIF-OUT.W1 8
Operation with process controller (C0238 = 0, 1):
Act. process controller value (PCTRL1-ACT)
Operation without process controller (C0238 = 2):
Output frequency without slip (MCTRL1-NOUT)
2 AIF-OUT.W2 0 Output frequency (MCTRL1-NOUT+SLIP)
3 CAN-OUT1.W1 /
FIF-OUT.W1
255 Not assigned (FIXED-FREE) • With Lenze setting, CAN-OUT1.W1
and FIF -OUT.W1 are defined as d igital
outputs and the 16-bit controller
status word 1 (C0417) is assigned to
them.
• Before you assign an analog signal
source (C0421/3
≠255), th e digital
assignment must be deleted
(C0417/x = 255)! Oth erwise the
output signal would be incorrect.
4 CAN-OUT1.W2 /
FIF-OUT.W2
255 Not assigned (FIXED-FREE)
5 CAN-OUT1.W3 /
FIF-OUT.W3
255 Not assigned (FIXED-FREE)
6 CAN-OUT1.W4 /
FIF-OUT.W4
255 Not assigned (FIXED-FREE)
7 CAN-OUT2.W1 255 Not assigned (FIXED-FREE)
8 CAN-OUT2.W2 255 Not assigned (FIXED-FREE)
9 CAN-OUT2.W3 255 Not assigned (FIXED-FREE)
10 CAN-OUT2.W4 255 Not assigned (FIXED-FREE)
