Free connection of digital signals
Free configuration of digital outputs
10
Function library
10.13
10.13.2
L
10.13-6
EDS82EV903-1.0-11/2002
10.13.2 Free configuration of digital outputs
l The digital outputs (X3/A1, X3/A2, relay output K1, relay output K2) can be
freely assigned to internal digital signals.
l A signal source can be assigned to several targets.
)
))
) Note!
l Use C0008 to assign some internal signal sources to the relay
output D1. C0415/1 is automatically adapted.
l Use C0117 to assign some internal signal sources to the digital
output X3/A1. C0415/2 is automatically adapted.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0415
v
Free configuration
of digital outputs
Output of digital signals to terminals
^
10.13-6
1 Relay output K1
(RELAY)
25 TRIP fault message (DCTRL1-TRIP) A selection under C0008 will be copied
to C0415/1. A change of C0415/1 sets
C0008 = 255!
2 Digital output
X3/A1 (DIGOUT1)
16 Ready for operation (DCTRL1-RDY) A selection under C0117 will be cop ied
to C0415/2. A change of C0415/2 sets
C0117 = 255!
3(A) Digital output
X3/A2 (DIGOUT2)
255 Not assigned (FIXED-FREE)
