Free connection of digital signals
Free configuration of digital process data output words
10
Function library
10.13
10.13.3
L
10.13-12
EDS82EV903-1.0-11/2002
Selection under C0415/x Relays/digital outp ut (not inverted)
32 Digital input X3/E1 Picks up/HIGH, if HIGH level is applied t o the
33 Digital input X3/E2
corresponding digital input
34 Digital input X3/E3
35 Digital input X3/E4
36 (A ) Digital input X3/E5
37 (A ) Digital input X3/E6
38 PTC input X2.2/T1, X2.2/T2 Picks up/HIGH, if the potential-free switch is
connected to X2.2/T1, X2.2/T2
40 ... 55 AIF control word (AIF-CTRL) Bit 0 ... Bit 15 Picks up/HIGH, if the corresponding bit is set
60 ... 75 CAN-IN1.W1 or FIF-IN.W1 bit 0 ... bit 15
80 ... 95 CAN-IN1.W2 or FIF-IN.W2 bit 0 ... bit 15
100 ... 115 CAN-IN2.W1 bit 0 ... bit 15
120 ... 135 CAN-IN2.W2 bit 0 ... bit 15
140 Torque threshold 1 reached (MSET1=MOUT) Picks up/HIGH, if the condition is met
141 Torque threshold 2 reached (MSET2=MOUT)
142 Process controller output limit reached (PCTRL1-LIM)
10.13.3 Free configuration of digital process data output words
l The digital process data output words can be freely assigned to internal
digital signals. With this you can summarise status information which will be
automatically assigned to status word bits:
– The configuration under C0417 is mapped to the AIF status word 1
(C0150), FIF output word 1 (FIF-OUT.W1) and output word 1 of the CAN
object 1 (CAN-OUT1.W1).
– The configuration under C0418 is mapped to the AIF status word 2
(C0151), FIF output word 2 (FIF-OUT.W2) and output word 1 of the CAN
object 2 (CAN-OUT2.W1).
l A signal source can be assigned to several targets.
Description
