Parameter set management
Parameter set changeover
10
Function library
10.17
10.17.2
L
10.17-5
EDS82EV903-1.0-11/2002
10.17.2 Parameter set changeover
During operation you can change between the four parameter sets of the
controller via digital signals. Thus 9 additional JOG values or additional
acceleration and deceleration times are available.
The parameter set changeover via digital signals is not possible if the automatic
changeover via DC-bus voltage is active!
Link C0410/13 (DCTRL1-PAR2/4) and C0410/14 (DCTRL1-PAR3/4)with a digital
signal source.
After being initialised, the controller always operates with parameter set 1. Only
when a signal for parameter set changeover is active, the controller changes the
parameter set.
)
))
) Note!
l C0410/13 and C0410/14 must be linked with the same signals
in all parameter sets!
l Start the parameter setting with the highest parameter set.
Parameterise the parameter set 1 at the end. In this way
undefined states can be prevented
l If the control mode (C0014) is different for the parameter sets,
you should only switch between the parameter sets when the
controller is inhibited (CINH).
Signal source
Active parameter set
Level at C0410/13 Level at C0410/14
A
c
t
i
v
e
p
a
r
a
m
e
t
e
r
s
e
t
LOW LOW Parameter set 1 (PAR1)
HIGH LOW Parameter set 2 (PAR2)
LOW HIGH Parameter set 3 (PAR3)
HIGH HIGH Parameter set 4 (PAR4)
)
))
) Note!
Use C0007 to link the changeover between parameter set 1 and
parameter set 2 with the digital inputs X3/E2 or X3/E3.
Description
Activation
