Lenze E82EV302K4C User Manual

Networking
Parallel operation of AIF and FIF interfaces
10
Function library
10.19
10.19.2
L
10.19-3
EDS82EV903-1.0-11/2002
10.19.2 Parallel operation of AIF and FIF interfaces
)
))
) Note!
Please observe the permissible combinations at parallel operation
of AIF and FIF interfaces. A trouble-free operation can only be
guaranteed when using permissible combinations.
Further information on parallel operation are included in the CAN
communication manual.
Possible combinations Communication module on AIF
Function module in FIF
(Design: Standard or PT)
Keypad
E82ZBC
1)
Keypad XT
EMZ9371BC
1)
LECOM
-A/B 2102.V001
-LI 2102.V003
-A 2102.V004
1)
LECOM-B
(RS485)
2102.V002
INTERBUS
2111/2113
INTERBUS-
Loop 2112
PROFIBUS-
DP
2131/2133
System bus
(CAN)
2171/2172
CANopen /
DeviceNet
2175
LON 2141
Standard I/O E82ZAFSC üü üü üü üü üü üü üü üü
Application I/O E82ZAFAC üü ü ü ü ü ü ü ü
INTERBUS E82ZAFIC üü ( ü) x x x x x x
PROFIBUS-DP E82ZAFPC üü ( ü) x x x x x x
LECOM-B (RS485) E82ZAFLC üü ( ü) x x x x x x
System bus (CAN )
System bus I/O-RS
System bus I/O
E82ZAFCC
E82ZAFCC100
E82ZAFCC200
üü üü üü üü üü üü üü üü
CANopen / DeviceNet
2)
E82ZAFD üü üü x x x x x x
AS-i E82ZAFFC üü üü x x x x x x
1)
Independently of the jumper position always supplied internally.
2)
In preparation
üü Combination possible, internal or external supply of the communication module
ü Combination possible, external voltage supply!
(
ü) Combination possible, communication module can only be used for parameter setting.
x Combination not possible
