Lenze E82EV302K4C User Manual

Braking operation with external brake resistor
8200 vector 15 ... 90 kW
13
Braking operation
13.4
13.4.2
L
13.4-4
EDS82EV903-1.0-11/2002
13.4.2 8200 vector 15 ... 90 kW
The brake resistor is connected to the frequency inverter 8200 vector 15... 90 kW
via the EMB9352-E brake chopper (accessories), which is connected to the DC
bus of the frequency inverter (terminals +UG, –UG). With low brake power the
EMB9351-E module (accessories) with integrated brake resistor can be used.
Brake choppers and brake modules can be connected in parallel.
General data and application conditions (EMB9351-E and EMB9352-E)
Conformity CE Low-Voltage Directive (73/23/EEC)
Approvals UL 508C Underwriter Laboratories (File-No E132659) Power Conversion Equipment
Vibration resistance Acceleration resistance up to 0.7g (Germanischer Lloyd, general conditions)
Climatic conditions Class 3K3 to EN 50178 (without condensation, average rela t ive humidity 85 %)
Degree of pollution VDE 0110 part 2 pollution degree 2
Packaging (DIN 4180) Dust packaging
Permissible temperature ranges Transport -25 °C ... +70 °C
P
e
r
m
i
s
s
i
b
l
e
t
e
m
p
e
r
a
t
u
r
e
r
a
n
g
e
s
storage -25 °C ... +70 °C
Operation 0 °C ... +55 °C
Reduce peak braking current by 2.5 %/
°Cabove+40°C
Permissible installation height 0 ... 4000 m a .m.s.l.
Reduce peak braking current by 5%/1000 a bove 1000 m a.m.s.l.
Mounting position vertical
Free space Above and below = 100 mm
Rating of the EMB9352-E brake chopper
EMB9352 -E brake chop per 8200 vector, 400 V, type E82EV ...
153K4B201 223K4B201 303K4B201 453K4B201 553K4B201 753K4B201 903K4B201
Threshold V
DC
[V DC] 765 (adjustable)
Peak braking current [A DC] 42
Max. continuous current [A DC] 25
Lowest permissible brake
resistance
[Ω] 18
Current reduction Reduce peak braking current by 2.0 %/°Cabove40°C
C
u
r
r
e
n
t
r
e
d
u
c
t
i
o
n
Reduce peak braking current by 5%/1000 a bove 1000 m a.m.s.l.
Switch-on cycle Max. 60 s braking with peak braking current , then at least 60 s break
Recommended Lenze brake
resistor
Order
No.
ERBD033R02K0 ERBD022R03K0 ERBD018R03K0 ERBD022R03K0 ERBD018R03K0 ERBD022R03K0 ERBD018R03K0
Number of brake choppers 1 1 1 2
1)
2
1)
3
1)
3
1)
1)
Connected in parallel
Rating of the EMB9351-E brake module
EMB9351 -E brake module
Threshold V
DC
[V DC] 765 (adjustable)
Peak braking current [A DC] 16
Peak brak ing p ower [kW] 12
Permanent braking power [kW] 0.1
Thermal capacity [kWs] 50
Current reduction Reduce peak braking current by 2.0 %/°Cabove40°C
C
u
r
r
e
n
t
r
e
d
u
c
t
i
o
n
Reduce peak braking current by 5%/1000 a bove 1000 m a.m.s.l.
Switch-on cycle Max. 4 s braking with peak braking current, then at least 400 s break
Brake resistor integrated [Ω] 47
Additional brake chopper for
8200 vector 15 ... 90 kW
