Installation électrique
Partie commande
Entrée analogique
5
177
EDKCSEX064 DE/EN/FR 6.0
5.3.2 Entrée analogique
AI-
AG
AI+
GND
82k5
X6
=
=
82k5
250R
X3
5
6
3.3 nF
3.3 nF
"
"
ECSXA015
Fig.5−8 Entrée analogique sur X6
Raccordement de blindage HF via connexion avec la terre fonctionnelle par
une surface importante (voir instructions de montage pour la fixation de
blindage ECSZS000X0B)
