3 Technical data
3.1 General data and operating conditions
Standards and operating conditions
Conformity CE
Low−Voltage Directive (2006/95/EG)
Approvals
UL 508C
Power Conversion Equipment
Underwriter Laboratories (File No. E132659)
for USA and Canada
CSA 22.2 No. 14
Max. permissible
Motor cable
length
shielded 50 m For rated mains voltage and switching frequency of
8 kHz
Packaging (EN ISO 4180) Shipping package
Installation l Installation into IP20 control cabinet
l For the "safe torque off" function (formerly "safe standstill"):
mounting in IP54 control cabinet
Mounting position vertically suspended
Free space
above ³ 65 mm
below ³ 65 mm
With ECSZS000X0B shield mounting kit: > 195 mm
to the sides can be mounted directly side by side without any clearance
Environmental conditions
Climate 3k3 in accordance with IEC/EN
60721−3−3
Condensation, splash water and ice
formation not permissible.
Storage IEC/EN 60721−3−1 1K3 (−25 ... + 55 °C)
Transport IEC/EN 60721−3−2 2K3 (−25 ... +70 °C)
Operation IEC/EN 60721−3−3 3K3 (0 ... + 55 °C)
l Atmospheric pressure: 86 ... 106 kPa
l Above +40 °C: reduce the rated
output current by 2 %/°C.
Site altitude 0 ... 4000 m amsl
l Reduce rated output current by
5 %/1000 m above 1000 m amsl.
l Over 2000 m amsl: Use is only
permitted in environments with
overvoltage category II
Pollution EN 61800−5−1, UL840: Degree of pollution 2
Vibration resistance Acceleration resistant up to 0.7 g (Germanischer Lloyd, general conditions)
