Technical Data
3-10 821XKlimaBA0399
3.6 Dimensions
3.6.1 Controller dimension
The controller dimensions depend on the mechanical installation
(see chapter 4.1).
3.6.2 Analog plug-in module
20
28
E1
E2
E3
E4
39
4,00 cm
4,80 cm
3,90 cm
0 - 10 V
0 - 20 m A
K35.0140
FIG 3 -1 Dimensions of analog plug-in module
