Commissioning
821XKlimaBA0399 5-1
5 Commissioning
The controllers are factory-set to drive a corresponding four-pole
standard asynchronousmotor. Furthersettingsarenot necessary.
- 230/400 V, 50 Hz
- 265/460 V, 60 Hz
- 280/480 V, 60 Hz
Onlya few settingsviathe8201 BB operating moduleor afieldbus
module are necessary to adapt your drive to your application. The
steps required are summarized in chapter 5.3 und in Kap. 5.4.
5.1 Before you switch on
Prior to initial switch-on of the controller, check the wiring for
completeness, short-circuit, and earth fault:
- Power connection:
- Via L1, L2 and L3
- Alternatively via terminals +UG, -UG (DC-group drive)
- Control terminals:
- Reference potential for the control terminals is terminal 39.
- Controller enable: terminal 28
- Selection of direction of rotation: terminal E3 or E4
- External setpoint selection: terminals 8, 9
- Check jumper position! Factory setting: 0 - 10 V
(see the table in chapter 4.2.3.2).
- During operation with an internal voltage supply via
terminal 20, bride the terminals 7 and 39.
- In case of condensation connect the controller to mains
voltage only after the visible humidity has evaporated.
Maintain the switch-on sequence!
