Lenze I51AE175B Mounting And Switch-On Instructions

NOTICE
▶
UL marking
▶
Internal overload protecon rated for 125 % of the rated FLA.
▶
Marquage UL
▶
Protecon contre les surcharges conçue pour se déclencher à 125 % de l'intensité assignée à pleine
charge.
Fusing data
Branch Circuit Protecon (BCP)
Short Circuit Current Rangs (SCCR) with Standard Fuses and Circuit Breaker
(Tested per UL61800-5-1, reference UL le E132659)
These devices are suitable for motor group installaon when used with Standard Fuses or Circuit Breaker.
For single motor installaon, if the fuse value indicated is higher than 400 % of the motor current (FLA), the
fuse value has to be calculated. If the value of the fuse is below two standard rangs, the nearest standard
rangs less than the calculated value shall apply.
Inverter Standard Fuses (UL248) Circuit Breaker (UL489)
Mains
Rated
power
Max.
SCCR
Max. rated current Class
Max.
SCCR
Max. rated current Min. cabinet dimensions
kW hp kA A kA A m³ ³
230 V, 1-ph 0.25 0.33 65 15 CC 65 15 0.042 1.48
230 V, 1-ph 0.37 0.5 65 15 CC 65 15 0.042 1.48
230 V, 1-ph 0.55 0.75 65 15 CC 65 15 0.042 1.48
230 V, 1-ph 0.75 1 65 15 CC 65 15 0.042 1.48
230 V, 1-ph 1.1 1.5 65 30 CC, J, T 65 30 0.042 1.48
230 V, 1-ph 1.5 2 65 30 CC, J, T 65 30 0.042 1.48
230 V, 1-ph 2.2 3 65 30 CC, J, T 65 30 0.042 1.48
230 V, 1/3-ph 0.25 0.33 65 15 CC 65 15 0.042 1.48
230 V, 1/3-ph 0.37 0.5 65 15 CC 65 15 0.042 1.48
230 V, 1/3-ph 0.55 0.75 65 15 CC 65 15 0.042 1.48
230 V, 1/3-ph 0.75 1 65 15 CC 65 15 0.042 1.48
230 V, 1/3-ph 1.1 1.5 65 30 CC, J, T 65 30 0.042 1.48
230 V, 1/3-ph 1.5 2 65 30 CC, J, T 65 30 0.042 1.48
230 V, 1/3-ph 2.2 3 65 30 CC, J, T 65 30 0.042 1.48
230 V, 3-ph 4 5 65 40 J, T 65 40 0.042 1.48
230 V, 3-ph 5.5 7.5 65 40 J, T 65 40 0.042 1.48
480 V, 3-ph 0.37 0.5 65 15 CC 65 15 0.042 1.48
480 V, 3-ph 0.55 0.75 65 15 CC 65 15 0.042 1.48
480 V, 3-ph 0.75 1 65 15 CC 65 15 0.042 1.48
480 V, 3-ph 1.1 1.5 65 15 CC 65 15 0.042 1.48
480 V, 3-ph 1.5 2 65 15 CC 65 15 0.042 1.48
480 V, 3-ph 2.2 3 65 15 CC 65 15 0.042 1.48
480 V, 3-ph 3 4 65 25 CC, J, T 65 25 0.042 1.48
480 V, 3-ph 4 5 65 25 CC, J, T 65 25 0.042 1.48
480 V, 3-ph 5.5 7.5 65 25 CC, J, T 65 25 0.042 1.48
480 V, 3-ph 7.5 10 65 40 J, T 65 40 0.042 1.48
480 V, 3-ph 11 15 65 40 J, T 65 40 0.042 1.48
Electrical installaon
Connecon according to UL
Important notes
32
