Lenze I51AE175B Mounting And Switch-On Instructions

Terminal data
Rated power P
rated
kW 0.25 ... 0.75 1.1 ... 2.2 4 ... 5.5
Connecon descripon Mains connecon
Connecon X100
Connecon type Pluggable Non-pluggable
Max. cable cross-secon mm² 2.5 6 6
Max. cable cross-secon AWG 12 10 10
Stripping length mm 8 8 9
Stripping length in 0.3 0.3 0.35
Tightening torque Nm 0.5 0.7 0.5
Tightening torque lb-in 4.4 6.2 4.4
Required tool Screwdriver 0.5 x 3.0 Screwdriver 0.6 x 3.5
Rated power P
rated
kW 0.25 ... 5.5
Connecon descripon PE connecon
Connecon PE screw
Max. cable cross-secon mm² 6
Max. cable cross-secon AWG 10
Stripping length mm 10
Stripping length in 0.4
Tightening torque Nm 2
Tightening torque lb-in 18
Required tool Torx key 20
Rated power P
rated
kW 0.25 ... 2.2 4 ... 5.5
Connecon descripon Motor connecon
Connecon X105
Connecon type Pluggable Non-pluggable
Max. cable cross-secon mm² 2.5 6
Max. cable cross-secon AWG 12 10
Stripping length mm 8 9
Stripping length in 0.3 0.35
Tightening torque Nm 0.5 0.5
Tightening torque lb-in 4.4 4.4
Required tool Screwdriver 0.5 x 3.0 Screwdriver 0.6 x 3.5
Electrical installaon
Mains connecon
3-phase mains connecon 230/240 V
40
