Lenze I51AE175B Mounting And Switch-On Instructions

3-phase mains connecon 480 V "Light Duty"
Rated data
The output currents apply to these operang condions:
•
At a switching frequency of 2 kHz or 4 kHz: Ambient temperature above 40 °C with a rated output current
reduced by 2.5 %/°C.
•
If the load characterisc "Light Duty" and the switching frequencies 8 kHz or 16 kHz are selected, only the
values of the load characterisc "Heavy Duty" are reached.
Inverter I51AE I51BE I51AE I51BE I51AE I51BE I51AE I51BE
230F 240F 255F 275F 311F
Rated power P
rated
kW 4 5.5 7.5 11 15
Rated power P
rated
hp 5 7.5 10 15 20
Mains voltage range 3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 - 400/480 V
Rated mains current
without mains choke A 8.6 11.2 15.3 22 -
with mains choke A 6.8 8.8 12.1 17.2 22.6
Apparent output power kVA 5.9 8 10.5 15 19
Rated output current
2 kHz A 6.3 8.1 10.9 13.9 17
4 kHz A 6.3 8.5 10.8 13.2
8 kHz A -
16 kHz A -
Power loss
2 kHz W 94 125 163 238 290
4 kHz W 100 133 173 253 309
8 kHz W -
16 kHz W -
Cyclic mains switching 3 mes per minute
Brake chopper
Max. output current -
Min. brake resistance -
Max. motor cable length
shielded
without EMC category m 100
Category C1 (2 kHz, 4 kHz,
8 kHz)
m -
Category C2 (2 kHz, 4 kHz,
8 kHz)
m 20
Category C3 (2 kHz, 4 kHz,
8 kHz)
m 35 50
Max. motor cable length
unshielded
without EMC category m -
Technical data
3-phase mains connecon 480 V "Light Duty"
Rated data
65
