Lenze I51AE175B Mounting And Switch-On Instructions

3-phase mains connecon 480 V
Rated data
The output currents apply to these operang condions:
•
At a switching frequency of 2 kHz or 4 kHz: Max. ambient temperature 45 °C.
•
At a switching frequency of 8 kHz or 16 kHz: Max. ambient temperature 40 °C.
Inverter I51AE I51BE I51AE I51BE I51AE
137F 155F 175F 211F 215F 222F 230F 240F 255F 275F
Rated power P
rated
kW 0.37 0.55 0.75 1.1 1.5 2.2 3 4 5.5 7.5
Rated power P
rated
hp 0.5 0.75 1 1.5 2 3 4 5 7.5 10
Mains voltage range 3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 - 400/480 V
Rated mains current
without mains choke A 1.5 2.1 2.8 3.7 4.5 6.5 8 10.5 14.3 16.6
with mains choke A 1.2 1.7 2.2 2.5 3.1 4.4 5.8 7.5 10.3 13.1
Apparent output power kVA 0.9 1.2 1.6 2.2 2.6 3.8 4.9 6.4 8.7 11
Rated output current
2 kHz A - 1.6 2.1 3 3.5 4.8 6.3 8.2 11 14
4 kHz A 1.1 1.6 2.1 3 3.5 4.8 6.3 8.2 11 14
8 kHz A 1.1 1.6 2.1 3 3.5 4.8 6.3 8.2 11 14
16 kHz A 0.7 1.1 1.4 2 2.3 3.2 4.2 5.5 7.3 9.3
Power loss
2 kHz W - 24 30 38 45 62 79 102 137 172
4 kHz W 20 25 32 40 48 66 85 110 145 185
8 kHz W 24 31 40 51 61 85 110 140 190 240
16 kHz W 24 31 40 51 61 85 109 140 189 238
Cyclic mains switching 3 mes per minute
Brake chopper
Max. output current -
Min. brake resistance -
Max. motor cable length
shielded
without EMC category m 15 50 100
Category C1 (2 kHz, 4 kHz,
8 kHz)
m - 3 -
Category C2 (2 kHz, 4 kHz,
8 kHz)
m 15 20
Category C3 (2 kHz, 4 kHz,
8 kHz)
m 15 20 35 50
Max. motor cable length
unshielded
without EMC category m -
Technical data
3-phase mains connecon 480 V
Rated data
63

Lenze I51AE175B Specifications
