Lenze I51AE175B Mounting And Switch-On Instructions

Terminal data
Rated power P
rated
kW 0.25 ... 0.75 1.1 ... 2.2
Connecon descripon Mains connecon
Connecon X100
Connecon type Pluggable
Max. cable cross-secon mm² 2.5 6
Max. cable cross-secon AWG 12 10
Stripping length mm 8 8
Stripping length in 0.3 0.3
Tightening torque Nm 0.5 0.7
Tightening torque lb-in 4.4 6.2
Required tool Screwdriver 0.5 x 3.0 Screwdriver 0.6 x 3.5
Rated power P
rated
kW 0.25 ... 2.2
Connecon descripon PE connecon
Connecon PE screw
Max. cable cross-secon mm² 6
Max. cable cross-secon AWG 10
Stripping length mm 10
Stripping length in 0.4
Tightening torque Nm 2
Tightening torque lb-in 18
Required tool Torx key 20
Rated power P
rated
kW 0.25 ... 2.2
Connecon descripon Motor connecon
Connecon X105
Connecon type Pluggable
Max. cable cross-secon mm² 2.5
Max. cable cross-secon AWG 12
Stripping length mm 8
Stripping length in 0.3
Tightening torque Nm 0.5
Tightening torque lb-in 4.4
Required tool Screwdriver 0.5 x 3.0
Electrical installaon
Mains connecon
1-phase mains connecon 230/240 V
36
