Lexmark E460DN Service Manual

5-4 Service Manual
4513-630, -63W, -6EW
Lexmark E460dn, E460dw controller board connector pin values
Note: See the wiring diagram at back of book.
These values were measured with all connections made (plugged) or with only one connector at a time
unplugged to expose the pins. Always disconnect and connect with the printer power off. Otherwise, the values
below may not match.
Connector Pin # Value
cable plugged
Value
cable unplugged
(if different)
Comments
J2 1, 2, 3, 4 0 V dc Wireless card (E460 dw only)
55 Vdc
63.3 Vdc
J4 1 Ground Cartridge
(The front access door must be closed.)
21.7 Vdc
3, 4 3.3 V dc
J5 1, 3, 5, 6 3.3 V dc Operator panel
25.0 Vdc
4, 7 Ground
J100 1 > 0 V dc 5 V dc Printhead
2, 3 5 V dc
4, 5, 6, 7 Ground
J7 1 5 V dc (door closed) Open door sensor
0 V dc (door open)
25 Vdc
3 Ground
J8 1, 10 5 V dc LSU
92.9 Vdc
J9 1 24 V dc 0 V dc Cooling fan
2 24 V dc
J10 1 24 V dc 24 V dc Duplex solenoid
2 24 V dc 0 V dc
J11 1 5 V dc Narrow media sensor
25 Vdc 5 Vdc
3 Ground
J12 1 5 V dc Thermistor
2 Ground
J13 1 0.6 V dc Toner level sensor
2 Ground
30 Vdc
J14 1 > 0 V dc 5 V dc Fuser exit sensor
25 Vdc
3 Ground

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
