Lexmark E460DN Service Manual

Index I-1
4513-630, -63W, -6EW
Index
A
abbreviations 1-9
acronyms 1-9
B
buttons
accessing service menus
3-1
C
Charge Roll, diagnostics mode 3-15
compatibility 1-4
configuration ID 3-14
configuration menu
accessing
3-1, 3-2
available menus 3-2
Demo Mode 3-4
Energy Conserve 3-5
Factory Defaults 3-4
Panel Menus 3-4
PPDS Emulation 3-4
control panel 1-2
controller card
service check
2-23
D
defaults
factory defaults
3-4
diagnostics mode 3-6
accessing 3-1
available tests 3-6
diagnostics mode—
EP Setup
Charge Roll
3-15
EP Defaults 3-15
Fuser Temp 3-15
Gap Adjust 3-15
Print Contrast 3-15
Transfer 3-15
Event Log
Clear Log
3-17
Display Log 3-16
Print Log 3-17
Hardware Tests
DRAM Test
3-9
Printer Setup
Configuration ID
3-14
Edge to Edge 3-14
Engine Settings 3-14
Model Name 3-14
Par S Strobe Adj 3-14
Registration 3-7
DRAM Test 3-9
E
Edge to Edge 3-14
EP Defaults 3-15
error log
clear log (diagnostics mode)
3-17
display log (diagnostics mode) 3-16
Print Log 3-17
error messages
service error codes
2-15
user attendance messages 2-5
ESD-sensitive parts 4-1
F
fan
parts catalog
7-5
service check 2-24
frame, parts catalog 7-6
fuser
parts catalog
7-5
service check 2-26
Fuser Temp 3-15
G
Gap Adjust 3-15
H
handling ESD-sensitive parts 4-1
History
see error log
3-17
L
lithium battery v-xiii, 4-6
locations
front views
5-1
rear views 5-1
lubrication specifications 6-1
LVPS/HVPS
parts catalog
7-5
service check 2-26
M
maintenance approach 1-1
maintenance kits 6-1
menus
accessing service menus
3-1
messages
service error codes
2-15
user attendance messages 2-5
Model Name 3-14
models
comparison
1-1
diagrams 5-1
operator panels 1-2
trays available 1-5
N
navigation buttons 2-2

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
