Lexmark E460DN Service Manual

Diagnostic aids 3-5
4513-630, -63W, -6EW
Action For Prompts
This setting determines which input source receives paper-related or envelope-related change prompts when
they occur. Press to enter Action For Prompts from the Configuration Menu. The following displays:
Press to select a prompt. Submitting Selection displays. The screen automatically returns to the
Configuration Menu.
Press to exit the Env Prompts setting at anytime.
Energy Conserve
This menu controls what values appear on the Power Saver menu. If Off is selected in the Energy Conserve
menu, then the Power Saver can be turned off. If On (default) is set in Energy Conserve, then the Power Saver
feature cannot be turned off.
Font Sharpening
This menu allows a user to set a text point-size value below which the high-frequency screens will be used when
printing font data. For example, if this setting’s value is “24,” then all fonts sized 24 points or less will use the
high-frequency screens. To increase this setting’s value by 1, press . To decrease this setting’s value by 1,
press .
Exit Configuration Menu (Exit Config Menu)
Press to exit the Configuration menu. The printer performs a POR and restarts in normal mode.
Action For Prompts
✔*Prompt user
Continue
Use Current

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
