Lexmark E460DN Service Manual

3-6 Service Manual
4513-630, -63W, -6EW
Diagnostics menu
Entering Diagnostics menu
1. Turn off the printer.
2. Press and hold and .
3. Turn on the printer.
4. Release the buttons when the clock displays.
Available tests
The tests display on the operator panel in the order shown:
Note: Menus may vary depending on the features and options of the printer.
Registration See “Registration” on page 3-7.
Print tests See “Print Tests” on page 3-8.
Hardware tests See “Hardware Tests” on page 3-9.
Duplex tests See “Duplex Tests” on page 3-10.
Input Tray Tests See “Input Tray Tests” on page 3-11.
Output Bin Tests See “Output bin tests” on page 3-12.
Base Sensor Test See “Base Sensor Test (B. Sensor Test)” on page 3-12.
Printer setup See “Printer Setup” on page 3-13.
EP Setup See “EP Setup” on page 3-15.
Reports See “Reports” on page 3-16.
Event Log See “Reports” on page 3-16.
Exit Diagnostics See “Exit Diagnostics” on page 3-17.

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
