Lexmark E460DN Service Manual

3-10 Service Manual
4513-630, -63W, -6EW
Duplex Tests
The following tests are used to determine if the duplex is working correctly:
• Quick Test
• Top Margin
• Left Margin
• Sensor Test
• Duplex Feed 1
Quick Test
The Quick Test contains the following information on a duplexed page:
• Print registration settings
• Alignment diamonds at the top and bottom
• Horizontal lines to check for skew
• General printer information, including current page count, installed memory, serial number,
and code level.
To print the duplexed Quick Test page:
1. Select Quick Test from the DUPLEX TESTS menu.
2. Select Single or Continuous by pressing or .
3. Press to print the page.
Top Margin
1.
Select Top Margin from the DUPLEX TESTS menu.
2. To change the margin value, press to increase the value or to decrease the value.
3. Press to save the desired margin value.
Left Margin
1.
Select Left Margin from the DUPLEX TESTS menu.
2. To change the margin value, press to decrease the value or to increase the value.
3. Press to save the desired margin value.
Sensor Test
This test is used to determine if the input sensor is operating correctly.
• If the sensor is operating correctly, then OP (Open) will appear on the display:
• Press to return to the DUPLEX TESTS menu.
Sensor Test
Input=OP

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
