Lexmark E460DN Service Manual

2-8 Service Manual
4513-630, -63W, -6EW
Cartridge error messages
Error Description Action
30.XX Cartridge errors
30.01 No bucket transition out of the top bucket. If the cartridge
has not been refilled, then it usually is a mechanical
problem with the cartridge. During development, it could
also have the wrong chip installed.
Replace the cartridge.
30.02 No bucket transition out of the middle buckets. If the
cartridge has not been refilled, then it usually is a
mechanical problem with the cartridge. During
development, it could also have the wrong chip installed.
30.03 No bucket transition out of the lowest bucket. If the
cartridge has not been refilled, then it usually is a
mechanical problem with the cartridge. During
development, it could also have the wrong chip installed.
30.04 Excessive bucket jump. If the cartridge has not been
refilled, then it usually is a mechanical problem with the
cartridge.
30.05 Cartridge has run past it's life such that the cartridge has to
been totally void of printable toner. During development, it
could also have the wrong chip installed.
31.XX Defective cartridge errors
31.01 Cartridge missing. Smartchip installed backwards or
missing. Cable loose on controller board. Bad, dirty or
broken contacts. Bad chip. Wrong cartridge installed.
Replace the cartridge.
31.02 Authentication Failure. Failed to authenticate the device,
possible cartridge is from another family, or the chip is
defective.
31.03 ECC Failure. Clone or defective device.
31.04 Read Failure. Intermittent contact with the device, cable on
system card not seated well, gross electrical noise,
defective device.
Check the contact pins (on the
right side, under the cartridge) for
damage. Replace if possible.
31.05 Write Failure. Intermittent contact with the device, cable on
system card not seated well, gross electrical noise,
defective device.
31.06 SRL. Clone device. Replace the cartridge.
31.07 Penalty. Too many POR/CC events have occurred.
31.08 Unsupported SC Firmware. Clone or defective device.
32.XX Unsupported cartridge errors

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
