Lexmark E460DN Service Manual

Diagnostics information 2-5
4513-630, -63W, -6EW
Messages and error codes
User attendance messages
The printer control panel displays messages describing the current state of the printer and indicates possible
printer problems that must be resolved. This topic provides a list of all printer messages, explains what they
mean, and tells how to clear the messages.
The following table lists the messages in alphanumerical order. A message can also be located using the index.
User attendance messages
Message Action
Activating Demo Mode Wait for the message to clear.
Activating Menu Changes Wait for the message to clear.
Activating/Deactivating PPDS Wait for the message to clear.
Busy Wait for the message to clear, or cancel the print job.
Cancelling Job Wait for the message to clear.
Change Cartridge Invalid Refill The printer has detected an unsupported refilled cartridge. Remove the
indicated print cartridge, and install a new one.
Close door Close the specified door to clear the message.
Deactivating Demo Mode Wait for the message to clear.
Defragmenting Flash DO NOT POWER OFF Warning: Do not turn the printer off while this message is displayed.
Wait for the message to clear.
Disabling Menus Wait for the message to clear.
Note: The printer settings cannot be changed from the control panel while
the menus are disabled.
Enabling Menus Wait for the message to clear.
Flushing Buffer Wait for the message to clear.
Formatting Flash DO NOT POWER OFF Warning: Do not turn the printer off while this message is displayed.
Wait for the message to clear.
Invalid Engine Code Download valid engine code to the printer.
Invalid Standard Network Code The code in an internal print server is not valid. The printer cannot receive
and process jobs until valid code is programmed into the internal print
server. Download valid code to the internal print server.
Note: The network code can be downloaded while this message is
displayed.
Load manual feeder with <Custom Type> • Load the specified media in the manual feed tray or multipurpose
feeder.
• To ignore the manual feed request and print on media already
installed in one of the input sources, press .
If the printer finds a tray that has media with the correct media type
and size, then it feeds media from that tray. If the printer cannot find
a tray with the correct media type and size, then it prints on
whatever media is installed in the default input source.
• Cancel the current job.
Load manual feeder with <Custom
String>
Load manual feeder with <size>
Load manual feeder with <size> <type>

Lexmark E460DN Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	64 MB
Processor frequency	466 MHz
Maximum internal memory	576 MB
Sound pressure level (printing)	53 dB
Total input capacity	300 sheets
Maximum input capacity	850 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, IPX/SPX, AppleTalk, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Recommended media weight	75 g/m²
Compatible operating systems	Windows 2000/ME/XP/98/XP Pro/Server 2003/2003 x64 Mac OS X, Mac OS 9.x
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1 3rd Edition, U.S. FDA, IEC 320-1, CSA, ICES Class B, Energy Star, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Weight	14030 g
Dimensions (WxDxH)	406 x 370 x 260 mm
