Clearing Tray 1 jams
If the paper did not feed from Tray 1 correctl
y
, the jam is in the tray.
Pa
per Jam A1: Remove Tray1 and Clear
Jam
appears. Tray 1 could
be the 250-shee
t letter-size tray or
the 250-she
et legal-size tray.
1
Pull Tray 1 out. Remove the tray completely.
2
Remove the jam. The jam could be in th
e tray or behind the tra
y area.
•
Jams in the tra
y
—Locate the single piece of pap
er lying on
top of the stack. Pull it strai
ght out.
73
72
74
