29
206-4186
FTG Mode of Operation Overview
FTG Mode via CPU or EBL
FTG Mode enables Pro:Idiom decryption and also allows logical channel mapping of physical channels.
There are two separate and distinct methods for configuring LD340H/LD343H/LD345H TVs for FTG Mode
of operation: one (new) method is to configure the TV CPU for FTG Mode operation, while the other is to
configure the TV EBL for FTG Mode operation. EACH OF THESE METHODS IS MUTUALLY EXCLUSIVE.
IF THE CPU IS IN FTG MODE, THE EBL CANNOT BE SWITCHED TO FTG MODE. LIKEWISE, IF THE
EBL IS IN FTG MODE, THE CPU CANNOT BE SWITCHED TO FTG MODE.
Caution: Once the initial method for conguring the TVs for FTG Mode of operation has been
selected, all subsequent changes to FTG Channel Map and FTG Installer Menu settings must
also be performed in accordance with the selected FTG Mode of operation (via CPU or EBL).
• FTG Mode via CPU: With this method, the TV’s CPU is congured with an FTG Channel Map and FTG
Installer Menu settings using one of the following processes:
− Congure an individual LD340H/LD343H/LD345H TV via its USB port using an FMA Conguration
(.fma) le on a USB memory device. The “Teach to TV (FMA)” process, along with associated proce-
dures, is described on pages 31 to 34.
− Congure all LD340H/LD343H/LD345H TVs at the site using a Pro:Centric server head end
device (Example: PCS150R). Load an FMA Conguration (.fma) le on the Pro:Centric server
using the TV E-Z Installation “Conguration” option in the Pro:Centric Server Admin Client. Refer to the
Pro:Centric™ Server Admin Client User Guide for further information.
• FTG Mode via EBL: With this method, the TV’s EBL module is congured with an FTG Channel Map and
FTG Installer Menu settings using one of the following processes:
− Congure an individual LD340H/LD343H/LD345H TV’s EBL via its TV-LINK CFG jack using a direct PC-
to-TV connection and the FTG Conguration Application. The “Write” process for an FTG Channel Map
and FTG Installer Menu settings is described on page 35.
− Congure all LD340H/LD343H/LD345H TV EBLs at the site using a Free-To-Guest Management
Appliance (FMA) head end device (Example: FMA-LG101). Refer to the Free-To-Guest (FTG) Con-
figuration Application manual and/or the Installation & Setup manual for the FMA device for further
information.
While the TV is in FTG Mode:
• Users can still access the Installer Menu using an LG Installer Remote; however, all Installer Menu items
will be read-only.
• Any FTG conguration changes must be made using the FTG Conguration Application. FTG Channel
Map Conguration and FTG Installer Menu Conguration Utilities enable you to make changes, respec-
tively, to the FTG Channel Map and FTG Installer Menu settings as necessary. Based on the initial method
used to congure the TV for FTG Mode operation (via CPU or EBL), all subsequent changes must be
transferred to the TV/EBL via a process that is in accordance with that method.
• If it becomes necessary to reset the TV to Pass-through Mode, there are several options that will enable
you to do so. Refer to Reference section, “Resetting a TV to Pass-through Mode,” for further information.
Pages 36 to 39 provide overviews of the FTG Channel Map, FTG Installer Menu, and FMA Configuration
Utilities that comprise the FTG Configuration Application. Refer to the Free-To-Guest (FTG)
Configuration Application manual for further information on the FTG Configuration Application.

LG 32LD330H Specifications

General

Equalizer	Yes
Audio system	Infinite Surround
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
Equalizer bands quantity	5
Product color	Black
Panel mounting interface	200 x 100 mm
Comb filter	3D
Display diagonal	32 \
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Supported video modes	720p
Contrast ratio (dynamic)	60000:1
Supported graphics resolutions	1366 x 768
Package depth	193.04 mm
Package width	985.51 mm
Package height	619.75 mm
Package weight	14650 g
Video formats supported	MPEG2, MPEG4
Number of OSD languages	4
On Screen Display (OSD) languages	ENG, ESP, FRE, KOR
Placement supported	Horizontal
Number of AV connections	1
Mean time between failures (MTBF)	60000 h
Certification	RoHS
HDMI version	1.3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	150 W
Power consumption (standby)	1 W
Power consumption (typical)	80 W
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC

Weight and Dimensions

Depth (with stand)	223.52 mm
Width (with stand)	805.18 mm
Height (with stand)	581.66 mm
Weight (with stand)	12560 g
Depth (without stand)	109.21 mm
Height (without stand)	528.31 mm
Weight (without stand)	11390 g
