36
206-4186
FTG Channel Map Conîš¿guration Utility
The FTG Channel Map Configuration Utility enables you to build a Channel Map with logical channel
numbers.
Note: Write, Read, and Learn functions in the FTG Channel Map Configuration Utility are used for direct
PC-to-TV FTG configuration of LD340H/LD343H/LD345H TVs (FTG Mode via EBL). These functions are
not applicable to the process of creating an FMA Configuration file to be saved to a USB memory device
(FTG Mode via CPU).
PRINT MAP
Click to display a printable
FTG Channel Map Report. The
report can also be exported as
an HTML or Text file.
EDIT/ADD MAP
Click to open the FTG Channel Map
Editor to create or edit an FTG
Channel Map (see next page).
FTG Conîš¿guration Application Utilities Overview
WRITE
Click to transfer the FTG Channel
Map to the EBL. This will switch the
EBL from Pass-through Mode to
FTG Mode.
READ
Click to transfer the FTG
Channel Map from the EBL to the
FTG Configuration Application.
LEARN
Click to transfer the TV Channel Map
from the PTC to the EBL and the FTG
Configuration Application. (Requires that
2-5-5 + MENU was performed to transfer
TV Channel Map to PTC.) *
*
Logical Channel numbers will automatically be assigned in ascending order,
starting with 0 (zero), to the Physical Channels from the TV Channel Map.
To Next Page
