Section 10. Programmers reference Page 71 / 107
10.3. Status and identification commands
10.3.1. View product type
Description: Identification of the device. Type ‘i’ or ‘I’ then the transmitter responds its
name.
Format
Example
Command
{I}
→
{i}
Response
(<PRODUCT_TYPE>)CrLf
←
(I:UMX-OPT-TX150R)CrLf
Legend: <PRODUCT_TYPE> shows the extender model.
Explanation: The connected device is an UMX-OPT-TX150R.
10.3.2. View serial number
Description: The extender responds its 8-digit serial number.
Format
Example
Command
{S}
→
{s}
Response
(<SERIAL_NUMBER>)CrLf
←
(SN:10170142)CrLf
Legend: < SERIAL_NUMBER > shows the serial number of the extender.
Explanation: The connected device’s serial number is 10170142.
Info: Only the last 4 numbers are written onto the back of the transmitter.
10.3.3. View Firmware version of the CPU
Description: View the CPU firmware revision.
Format
Example
Command
{F}
→
{f}
Response
(FW:<FW_VER><S>)CrLf
←
(FW:1.0.1r)CrLf
Legend: <FW_VERSION> is the firmware version. It is followed by <s> string which may
indicate special versions. <s>=r indicates standard version.
Explanation: The connected device’s firmware version is 1.0.1r.
10.3.4. View installed controllers’ firmware
Description: Shows the firmware revisions of the installed controllers.
Format
Example
Command
{FC}
→
{fc}
Response
(CF●END)CrLf
←
(CF END)CrLf
Explanation: There is no installed controller. This command is reserved for compatibility
reasons.
10.3.5. View device’s temperature
Description: Queries temperature status.
Format
Example
Command
{ST}
→
{st}
Response
(ST●CPU●<DESC>●
<TEMP>)CrLf
←
(ST CPU N/A N/A N/A N/A N/A 23.1C)CrLf
Legend: <DESC> N/A N/A N/A N/A N/A – reserved for compatibility reasons
<TEMP> The inner temperature.
Explanation: Internal temperature is 23.1 Celsius.
