7.2 LED Blinking statuses
Service /
status
LED status
Mains
Battery
Thigh Lock
Back rest lock
Lift lock
Foot controls
lock
Locked
-
-
Illuminated
Illuminated
Illuminated
Illuminated
Short circuit
Blinking 600ms
ON, 600ms
OFF
In antiphase
-
Blinking 600ms
ON, 600ms
OFF
Blinking 600ms
ON, 600ms
OFF
Blinking 600ms
ON, 600ms
OFF
Blinking 600ms
ON, 600ms
OFF
First fault
Blinking 600ms
ON, 600ms
OFF
-
-
-
-
-
Movement
block
-
-
Blinking 600ms
ON, 600ms
OFF
Blinking 600ms
ON, 600ms
OFF
Blinking 600ms
ON, 600ms
OFF
Blinking 600ms
ON, 600ms
OFF
Power
Illuminated
-
-
-
-
-
Power fault
Not illuminated
-
-
-
-
-
Battery NA or
defective
Illuminated
Illuminated
-
-
-
-
Battery defect
-
Illuminated
-
-
-
-
Battery very
discharged
-
Blinking
1600ms ON,
200ms OFF
-
-
-
-
Battery
discharged
completely
(Only CPR)
-
Blinking 100ms
ON, 100ms
OFF
-
-
-
-
Battery
charging
-
Blinking 200ms
ON, 1600ms
OFF
-
-
-
-
NOTE: First value always means blinking of the LED and the second value means the LED is turned off.
7.3 Beeping - Sound signals
Beeping
Sound signals
unlimited time
continuous
control box over heated
battery overcurrent
scale overloaded
actuator overloaded
intermittent
Disconnected main control
(LCD)
Beeps 600ms ON, 2.6s OFF
bedexit alarm
Beeps 600ms ON,
600ms OFF
-
-
limited time
Short 300ms
confirms the operation
function blocked
-
-
Short 1s
service mode
function movement
caused by leakage
-
-
Long 3s
Fault signalization
-
-
-
Long 3 min
Brake alarm Beeps1.1s ON,
1.1s OFF
-
-
-
