- 30
english
Select time / date.
If no values or no correct values have been entered
for the data and time, enter the correct values with
the numeric buttons here.
OK Proceed.
Select sound components.
This selection indicates which sound components
you want to use to hear your TV sound. Depending
on the selection, the sound component wizard starts
with which you can make further settings.
The sound component wizard is described from
page 90 and can also be started at any time
outside of first time operation (TV menu under
Connections ט Sound components).
OK Proceed.
Select the option.
With the selection, specify whether you want to
configure the available network adapter now. For
Perform now see Media menu from page 57
onwards. For Do not perform or perform later:
OK End of wizard.
Positioning/aligning DVB-T antenna
If you are receiving one or more DVB-T stations with picture and sound
interference then you should change the installation location and align-
ment of the antenna. Ask your dealer to tell you which channels are used
to broadcast the DVB-T stations in your region.
➠ In normal TV mode, without other displays.
A DVB-T station is received and selected.
MENU: Call TV menu.
Select Settings,
go to the menu line below.
Select Stations,
go to the menu line below.
Select Manual adjustment,
OK call manual adjustment.
The signal source is already on DVB-T due to the station
preselection.
Position and align the antenna in such a manner that
maximum values for C/N and Level are obtained.
Blue button: Start search.
Search for DVB-T stations one after another and compare
values for C/N and Level.
Then position/align the antenna to the weakest station
so that maximum values for C/N and Level are obtained.
The value for BER should be as low as possible.
Thereafter perform an automatic search for all DVB-T
stations (see page 41).
Initial installation
Time and date
Sound playback
via ...
Network
configuration
MANUAL ADJUSTMENT
Signal source DVB-T DVB-C DVB-S C
