LS tractor XG3037H User Manual

4 -29
(10) Recommended maximum specification of implements
z When attaching implements to the tractor, refer to the followings recommended as maximum
specification of each implement. DO NOT attach bigger implements then this specification. For other
implements, contact your authorized local dealer.
No. Implements Specification XG3032 XG3037
1
Trailer
(with 4-wheel)
Max volume
3.0 m³
(105 ft³)
2
Trailer
(with 2-wheel)
Max vertical load See section 4-4-(3) in this manual
3 Mid mower Max cutting width
1676 mm
(66 in.)
4
Rear mounted
mower
Max cutting width
1676 mm
(66 in.)
5 Flail Mower Max cutting width
1500 mm
(59 in.)
6 Sickle Bar Max cutting width
1676 mm
(66 in.)
7
Rear mounted
Sprayer
Max tank capacity -
8 Pull type Sprayer Max tank capacity -
9 Rotary Tiller Max tilling width
1520 mm
(59.0 in.)
1600 mm
(63 in.)
10 Bottom Plow Max size
1250 mm
(49 in.)
11
Disk harrow
(pull type)
Max working width -
12 Manure Spreader Max volume
2.5 m³
(88 ft³)
13 Front blade Max working width
1660 mm
(65 in.)
14 Rear blade Max working width
1524 mm
(60 in.)
15 Front loader
Max lift capacity
(Bucket pivot point)
990 kg
(2182 lb)
16 Landscape Rake Max working width
1829 mm
(72 in.)
17 Box blade Max working width
1372 mm
(54 in.)
18 Backhoe
Max weight
(W/O Bucket)
470 kg
(1036 lbs)
19 Snow Blade Max. width
1600 mm
(63 in.)
20 Snow Blower Max. working width
1727 mm
(68 in.)

LS tractor XG3037H Specifications

General

Brand	LS tractor
Model	XG3037H
Category	Tractor
Language	English
