2 -2
2-1. Boarding and Exiting the tractor
(1) Boarding the tractor
① Roll-Bar type
z Whenever possible, use the left-hand side step
for boarding.
z When boarding the tractor, use the sub-step,
grab handle and steering wheel on the left fender.
z Do not jump up/down for your safety.
▶ Operator’s condition : The persons such as patients, drunks, people on drugs,
etc. are never allowed to operate this tractor.
Only well educated operators can use the tractor after learning the usage of
controls for moving, stopping, turning and other operating.
▶ Do not grasp the gear levers when entering the cabin from the right-hand side.
Caution
Sub step
Grab handle
warning
▶DO NOT arbitrarily remove the seat switch. When replacing the seat, check if the
seat switch has been changed together. If not, the engine can not be started.
(2) Driver’s seat
z At the lower end of the seat, there is a switch to
detect that operator is sitting in driver’s seat.
z If the operator gets up from the seat while
engine is running, the engine will stop
automatically for safety in case of ;
① getting up from the seat for more than 2
seconds with HST pedal NOT in neutral position.
② the HST pedal is in NEUTRAL and rear PTO is
engaged without applying parking brake.
③ the Middle PTO lever (optional) is engaged.
z Before leaving the driver’s seat,
- turn the PTO switch to OFF.
- place the middle PTO lever (optional) in OFF.
- apply the parking brake.
Seat switch
