LS tractor XG3037H User Manual

3 -3
(1) Instrument panel
5
24
6
7
9
10
11
14
10
18
15
17
19
2
3
4
23
21
22
22
Quick turn indicator (Not used)
3
4WD indicator (Not used)
4
PTO operation indicator
5
One side brake indicator (Not used)
6
Engine coolant temperature gauge
7
Cold start aid indicator
8
Engine warning indicator
9
High beam indicator
10
Turn signal indicator (Left/Right)
11
Hour meter
14
Error diagnosis code display
15
Battery charging indicator
16
Fuel filter warning indicator
17
Hydraulic oil pressure indicator (Not used)
18
Fuel level gauge
19
Engine oil pressure indicator
20
Parking brake indicator
21
Cruise drive indicator (HST only)
1
Forward-reverse indicator (Not used)
1
8
13
16
20
12
22
DPF Regeneration indicator
23
DPF temperature indicator
24
DPF inhibited indicator
13
EHL mode display (Not used)
12
Tachometer
