5 -11
(4) Turn signal lights, Lights and Horn
z
Check the operation status of light, turn signal lights, horn etc.
Horn switch
Turn signal
light switch
Light switch
z
If the light is OFF suddenly when operating the switch, check the problems as followings.
1. Check the relating fuse in the fuse box.
2. Check the light bulb. If necessary, replace it by a new one as referring to below.
▶
Use the bulb of rated capacity.
▶
In case of using the improper bulb, it may cause a failure of electric system
Notice
Illumination lights Light bulb specification
Head lights (Low beam / High beam) 12V 55W / 60W
Turn signal lights (front) 12V 21W
Side lights(front) 12V 10W
Turn signal lights (rear) 12V 10W
Brake lights / Tail lights(rear) 12V 21W / 5W
Work lights 12V27W (Grille) / 27W (Roll-bar)
Indoor light N/A
Instrument panel lights and indicators LED
