5 -20
5-9. Every 250 hour check
(1) Replacing Engine oil and Filter
▶
When engine oil is warm, the
impurities can be drained
completely.
Notice
①
Drain Engine oil
z
Run engine for a few minutes to warm oil
z
Park the tractor on a level surface.
z
Remove a drain plug of oil pan and drain the oil
completely.
Close
Open
Oil filling inlet
Drain plug
Packing
③
Fill Engine oil
z
Tighten the drain plugs. (Tightening torque :
40
±
5 N.m) (29.5
±
5 lbs-ft)
z
Add engine oil and check if the oil level is
between MIN and MAX mark on gauge.
z
For oil specification, see section 5-3, “Lubricants
and Capacity” or the last page in this manual.
z
Check any leakage of the engine while running
the engine for several minutes at idle rpm.
z
Stop the engine. After about 5~10 minutes later,
check the oil level again.
z
Install the oil gauge.
②
Replace Engine oil filter
z
Clean carefully around the filter.
z
Coat clean engine oil on the packing of new filter
and check the packing is placed well in the
groove.
z
Turn the oil filter counter-clockwise to remove
with filter wrench.
z
Turn the new filter clockwise to assemble until the
packing makes contact with the mounting surface.
Tighten ¾ to 1 turn more after packing contact.
z
If the metal is attached to the element of oil filter
to be disassembled, contact your authorized
dealer.
Engine oil gauge
To Next Page
