Manitowoc National Crane 800D User Manual

HOIST 800D
11-16
Published 5-27-2018 Control # 039-06
BILL OF MATERIAL
SEQ QTY DESCRIPTION
1
1 SIDE PLATE
2
8 CAPSCREW
3
1 RETAINING RING
4
1 OUTPUT GEARSET
4-1
1 CARRIER
4-2
3 OUTPUT PLANET GEAR
4-3
3 PLANET PIN
4-4
3 RETAINING RING
4-5
1 THRUST PLATE
4-6
6 BEARING
4-7
3 SPACER
4-8
6 WASHER
5
1 DRUM
6
2 RACE
7
1 SEAL KIT
7-1
1 O-RING
7-2
1 O-RING
7-3
1 O-RING
7-4
2 OIL SEAL
7-5
1 OIL SEAL
7-6
1 O-RING
7-7
1 BACKUP RING
7-8
1 BACKUP RING
7-9
2 O-RING
7-10
1 O-RING
8
1 INPUT SUN GEAR
9
14 CAPSCREW
10
1 BRAKE PISTON
11
4 CAPSCREW
13
1 BRAKE DRIVER
14
2 RACE
15
2 RETAINING RING
16
1 OUTPUT SUN GEAR
17
2 BUSHING
18
7 FRICTION DISC
19
8 STATOR PLATE
20
1 BRAKE COVER
21
1 BRAKE HOUSING
24
12 BRAKE SPRING
26
1 BEARING CARRIER
28
2 BEARING
Fo
r
Reference
Only
