The test result error messages may appear on the test result screens after test is
complete. The Table 6-3 below shows the messages.
Table 6-3. Test Result Error Messages
Error Message Description of error and action required
RATIO< Turns ratio is less than 0.8. Check for any wrong
connections.
RATIO> Turns ratio is greater than 20000. Check for any wrong
connections.
The miscellaneous error messages may appear on the screens during saving,
printing, or uploading functions. The Table 6-4 below shows the messages.
Table 6-4. Miscellaneous Messages
Error Message Description of error and action required
MEMORY IS
FULL.DELETE
A CONFIG.? 0=NO 1=YES
The maximum number of custom configurations have been
saved. In order to save this one, one has to be deleted.
MEMORY IS
FULL.DELETE
TEST RESULT? 0=N 1=Y
The maximum number of tests have been saved. In order to
save this one, one has to be deleted.
PRINT ERROR There was an error during printing a report. Try again. If
failed, contact the factory for repair.
TRANSFER ERROR There was an error while transferring test results to a PC. Try
again. If failed, contact the factory for repair.
When an error message appears on a screen indicating an abnormal operating
condition, verify the condition by taking a repeat measurement before attempting
to take any corrective action. Also, refer to the Troubleshooting section for
malfunctions and possible causes.
Open connections, wrong connections, open windings, shorted windings, high
resistance windings, other abnormal transformer problems, or a combination of
these may cause a large deviation from normal turn ratio or indicate an unusual
