389
Practical hints
Opening/closing in an emergency
왔 Opening/closing in an emergency
Power tilt/sliding sunroof
You can open or close the tilt/sliding
sunroof manually should an electrical
malfunction occur.
The tilt/sliding sunroof drive is located
behind the lens 1 of the interior overhead
light.
1 Lens
왘 Remove SmartKey from the starter
switch.
왘 Pry off lens 1 using a flat blade
screwdriver.
2 Locking tabs
왘 Slide both locking tabs 2 in direction
of the arrows.
왘 Lower the rear of the cover and
remove.
왘 Remove the cover.
왘 Take the crank 3 out of the Operator’s
Manual pouch.
3 Crank
왘 Insert crank 3 through hole on the left
side.
왘 Turn crank 3 clockwise to:
앫 slide sunroof closed
앫 raise sunroof at the rear
왘 Turn crank 3 counterclockwise to:
앫 slide sunroof open
앫 lower sunroof at the rear
i
Do not disconnect electrical
connectors.
컄컄
To Next Page
