Instrument cluster
31
Function Page
1 Coolant temperature gauge
345
2 Fuel gauge with:
Fuel tank reserve warning
lamp 535
A High-beam headlamp
indicator lamp
319
- Antilock Brake
System (ABS) indicator
lamp
528
= Supplemental
Restraint System (SRS)
indicator lamp 532
3 Parktronic/Park Assist
warning indicator for left
front area
368,
371
4 Multifunction display
with:
Speedometer
0 Electronic parking
brake warning or indicator
lamps, USA only 529
Function Page
! Electronic parking
brake warning or indicator
lamps, Canada only
529
; Brake warning lamp,
USA only
528
3 Brake warning lamp,
Canada only
528
< Seat belt telltale
531
H Combination low tire
pressure/TPMS
malfunction telltale, USA
only
537
H Low tire pressure
telltale, Canada only
537
L Left turn signal
indicator lamp
K Right turn signal
indicator lamp
v ESP
®
warning lamp
531
Function Page
l Distance warning
lamp
1
534
5 Parktronic/Park Assist
warning indicator for right
front area
368,
371
6 Gear position/range
indicator 340
7 Tachometer with:
± Engine malfunction
indicator lamp
536
8 Program mode indicator
341
9 Main menus for control
system, multifunction
display 233
a Outside temperature
346
b Display with:
Additional speedometer 247
: PRE-SAFE
®
Brake
indicator
244
1
Vehicles without DISTRONIC Plus: Warning lamp without function. It illuminates when the ignition is on. It should go out when the engine is running.
At a glance
