Airbags
Overview of airbags
Driver's/front passenger seat:
1
Knee airbag
2
Driver's airbag
3
Front passenger airbag
4
Window airbag
5
Side airbag
6
Centre airbag
1
1)
Onl
y for certain countries.
Rear seats:
4
Window airbag
7
Side airbag
8
Rear airbag
The installation location of an airbag is identied
b
y the AIRBAG symbol. An additional arrow sym-
bol M indicates the installation location for cer-
tain airbags.
When enabled, an airbag can provide additional
protection for the respective vehicle occupant.
Potential protection provided by each airbag:
R
Knee airbag: thigh, knee and lower leg
R
Dr
iver's airbag, front passenger airbag: head
and ribcage
R
Window airbag: head
R
Side airbag: ribcage, also pelvis for front seat
occupants
R
Centre airbag: head and ribcage
R
Rear airbag: head
Information on child restraint systems on the front
passenger seat
&
WARNING Risk of injur
y or death if the co-
driver airbag is enabled
If the co-driver airbag is enabled, a child on
t
he co-driver seat may be struck by the co-
driver airbag during an accident.
NEVER use a rearward-facing child restraint
system on a seat with an ENABLED FRONT
AIRBAG; DEATH or SERIOUS INJURY to the
CHILD can occur.
When tting a c
hild restraint system to the front
passenger seat, observe the vehicle-specic infor-
mation (/ page 85). Also, always observe the
54
Occupant safety
