Changing
1. Remove the gear lube monitor from the bracket.
a - Gear lube monitor bracket
b - Gear lube monitor and cap
c - Retaining strap
2. Empty the contents of the gear lube monitor into a suitable container.
3. Install the gear lube monitor in the bracket.
4.
Bravo One X Models:
a. Remove the propeller.
b. Lower the sterndrive to the full down (in) position.
c. Remove the gear lube fill and drain plug and the sealing washers.
d. Drain the gear lube into a suitable container.
a - Fill and drain plug
b - Sealing washer
5.
Bravo Three X Models:
a. Place the sterndrive in the full trim limit out position.
b. Remove the fill and drain plug and the sealing washers.
c. Drain the gear lube into a suitable container.
Bravo Two X
Bravo Three X
a - Fill and drain plug
b - Sealing washer
a
b
14621
a
b
19777
Section 4 - Maintenance
Page 48 90-8M0145546 eng MAY 2018
