Midea MHC-V4W/D2N8-B Engineering Data

M thermal Mono
202005 81
Part 3 - Installation and Field Settings
Table 3-4.1: Wiring requirements
Item
Description
AC/DC
Required number of conductors
Maximum running current
1
Solar energy kit signal cable
AC
2
200mA
2
User interface cable
AC
5
200mA
3
Room thermostat cable
AC
2 or 3
200mA(a)
4
Boiler control cable
/
2
200mA
5
Thermistor cable for T1B
DC
2
(b)
9
DHW pump control cable
AC
2
200mA(a)
10
3-way valve control cable
AC
2
200mA(a)
11
3-way valve control cable
AC
2 or 3
200mAC
12
Thermistor cable
DC
2
(b)
13
Booster heater control cable
AC
2
200mA(a)
15
Power supply cable for unit
AC
2+GND(1-Phase)
3+GND(3-Phase)
31A (1-Phase)
15A (3-Phase)
16
Power supply cable for backup heater
AC
2+GND(1-Phase)
3+GND(3-Phase)
14A (1-Phase)
6A (3-Phase)
Midea CAC Confidential
