Technical Information
24
CVA615 Coffee System
When the water tank is installed, and contains at least 30-33
ounces of water; the Water Level Switch is activated and its
contacts close.
If the water quantity drops below the minimum quantity, the water
level switch is no longer activated and the contacts open.
After the switch opens, the water passing through the water pump
is registered via the flowmeter and recorded by the electronic unit
as up to 27 ounces of water is still available.
After the 27 ounces is calculated as being used, the display shows
“Fill water tank”. To prevent the water pump from running dry, about
3 – 7 ounces of water remains in the tank.
If the appliance is placed into the service mode the top line of the
display shows the switches that have been activated. A “7” is
displayed when the water tank is installed and filled with water.
Refer to section 6 – Service Mode for further information.
